416 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Expansion cards and backup units
Figure 310: Installing the GPGPU air duct top cover (C)
Figure 311: Installing the GPGPU air duct top cover (D)
Ê Ensure that all centering bars on the GPGPU air duct base and top cover
are are properly seated:
A 3 centering bars on the side, 2 on top
B 1 centering bar on the lower edge
