TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 71
Basic hardware procedures
Figure 16: Removing the rack mounting frame (B)
Ê Press down on the locking latch while slightly folding out the rack front cover.
Figure 17: Removing the rack mounting frame (C)
