TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 737
Cabling
15
SAS Cable
250 mm Y3963-V112
SAS backplane to SAS
expander board or SAS
controller
16 320 mm
Y3963-V101
Y3963-V151
17 470 mm
Y3963-V103
Y3963-V153
18 620 mm Y3963-V107
19 Multilane SAS Cable 420 mm Y3963-V201
2x 3.5-inch HDD extension
box to SAS expander board
or SAS controller
20 ODD SATA Cable 650 mm Y3958-V205 ODD to system board
21A USB 2.0 Cable 700 mm Y3973-V96
USB backup drive to system
board
21B USB 3.0 Cable 1000 mm Y4039-V100
USB backup drive to
USB 3.0 PCI interface card
22 BBU Cable 700 mm Y3987-V1 BBU to SAS controller
23
FBU Cable
(SAS 2.0 controllers)
- Y4032-V1 FBU to TFM module
24 NCSI Sideband Cable 75 mm Y4015-V101
Modular LAN controller to
system board
25
GPGPU / Coprocessor
Card Power Cable
600 mm Y3946-V701
Power backplane to GPGPU
/ coprocessor card
26
HDD / GPGPU /
Coprocessor Card
Power Cable
820 mm Y3952-V701
Power backplane to SAS
backplanes and GPGPU /
coprocessor card
27 SAS 3.0 Cable 470 mm Y4040-V8
SAS 3.0 backplane to
SAS 3.0 controller
28 SAS 2.0 / 3.0 Cable 300 mm Y4040-V14
SAS 3.0 backplanes to
SAS 2.0 controller
29
SAS 3.0 Out-of-Band
Cable
- Y4015-V601
SAS 3.0 backplane
to system board
30
FBU Cable
(SAS 3.0 controllers)
700 mm Y4031-V103 FBU to TFM module 4G / 8G
No. Name Length
Number
(T26139-)
Routing
Table 6: List of used cables
