iRMC-related status signals
I Note on the onboard LAN controller
The system board is equipped with a Gigabit Ethernet Controller that
supports transfer rates of 10 Mbit/s, 100 Mbit/s and 1 Gbit/s.
The separate management LAN connector is used as a management
interface (iRMC S4) and is prepared for operation with the Remote
Management. Optionally LAN connector 1 can also be used for iRMC S4
server management.
3
Global error
indicator
off No critical event (non-CSS component)
orange on
Prefailure detected
(non-CSS component)
orange
flashing
Non-CSS component failure
CSS indicator
off No critical event (CSS component)
yellow on Prefailure detected (CSS component)
yellow
flashing
CSS component failure
ID indicator blue on
Server has been highlighted using
ServerView Operations Manager, the
iRMC web frontend, or the ID button on
the front panel for easy identification
ID indicator
Global error
indicator
Description
blue flashing off
A remote connection has been
established. Local VGA output has
been disabled during the remote
session.
blue flashing orange flashing
An emergency flash of the iRMC
firmware is in progress.
Indicator Status Description
