Cinterion
®
EHS6 AT Command Set
19.7 AT^SSPI
EHS6_ATC_V03.001 15/12/3
Confidential / Released
Page 463 of 513
Parameter Description
Parameter returned by the AT^SSPI? read command.
Indicates whether or not the I²C or SPI channel is used. When the channel is open and the ME is in data mode,
the read command can only be used if one of the remaining interfaces is available.
[0] Not connected (channel closed). All following parameters are the factory set-
tings ^SSPI: 0,0010,0000,0000.
1 Connected (channel open, ME in data mode). All following parameters are the
values currently used, for example ^SSPI: 1,0010,0000,0000.
Parameter <basicConfiguration> is a 16 bit word which contains four subparameters to control the follow-
ing functions:
For SPI only:
0000 Length of SPI word = 8 bits
For SPI only: Parameter <extendedSpiConfiguration> is a 16 bit word which contains four subparameters
to control the following functions:
<connectionState>
(num)
<basicConfiguration>
(num)
Subparameter Bit Hexadecimal Selected function
Interface type D15 - D12 0
1
I²C bus (default)
SPI device
Port D11 - D8 0 Internal port
Data transfer rate D7 - D4 0
1
0
1
2
3
4
5
I²C at 100 kbps
I²C at 400 kbps (default)
SPI at 100 kbps
SPI at 250 kbps
SPI at 500 kbps
SPI at 1.083 Mbps
SPI at 3.25 Mbps
SPI at 6.5 Mbps
Protocol D3 - D0 0 ASCII (hex coding)
<wordLength>
(num)
<extendedSpiConfiguration>
(num)
Subparameter Bit Hexadecimal Selected function
SPI mode D15 - D12 0
1
2
3
Four different SPI modes. Phase and
polarity of all SPI modes are illustrated in
Section 19.7.1, Selecting SPI Mode.
Chip Select (CS) mode D11 - D8 0 One Chip Select per Transfer Frame.
Arrangement of bytes D7 - D4 0 Big endian
Bit sequence
(arrangement of bits on the SPI)
D3 - D0 0 MSB first
