HP LaserJet Enterprise M552 - Page 455

2. Continue to rotate the top of the roller toward the printer (callout 1), until two tabs (callout 2) snap into
place.
Figure 2-113 Reconnect two tabs
1
2
2
3. Install the roller cover.
Figure 2-114 Install the roller cover
ENWW Clean the printer 427
