HP LaserJet Enterprise M552 - Page 459

5. Release the green handle (callout 1), and then lower the paper guide (callout 2).
Figure 2-121 Lower the paper guide
2
1
6. Locate the tray pickup roller assembly.
Figure 2-122 Locate the tray pickup roller
ENWW Clean the printer 431
