Understanding the Router Chassis ! 115
Chapter 13: Monitoring the Router Chassis
Figure 32 shows the front and rear of the T320 Internet router chassis and installed
components.
Figure 32: T320 Router Chassis and Components
g
003255
Craft interface
Fan tray
FPCs
CIP
ESD point
Fan tray
Air intake
(air filter
inside)
Rack-mounting ears
PICs
T320 front T320 rear
Air exhaust
(RE0)
CB0
CB1
SCG1
Fan tray
PEM0
PEM1
SCG0
SIB0
SIB1
SIB2
Power
supplies
(RE1)
Routing
Engines
Air filter
