Getting MCS Hardware Information ! 367
Chapter 27: Monitoring the MCS
5. On the console or other management device connected to the Routing Engine
that is paired with the MCS you are removing, enter CLI operational mode and
issue the following command. The command shuts down the Routing Engine
cleanly, so its state information is preserved.
user@host> request system halt
Wait to continue until all software processes have shut down.
6. Flip the ends of the extractor clips outward.
7. Grasp the extractor clips and slide the unit about halfway out of the chassis.
8. Place one hand under the MCS to support it, slide it completely out of the
chassis, and place it on the antistatic mat or in the electrostatic bag.
9. Align the rear of the MCS with the guides inside the chassis and slide it in
completely.
10. Press the extractor clips on the left and right sides of the MCS inward.
11. Verify that the green LED labeled
OK on the MCS faceplate is lit. Also check the
host module LEDs on the craft interface to verify that the green LED labeled
ONLINE is lit for the host module to which the MCS belongs.
You can also verify correct MCS functioning by using the
show chassis environment mcs command.
12. Reinstall the rear component cover and tighten the screws at the corners to
secure it to the chassis.
Getting MCS Hardware Information
Steps To Take To get MCS hardware information, follow these steps:
1. Display the MCS Hardware Information on page 367
2. Locate the MCS Serial Number ID Label on page 368
Step 1: Display the MCS Hardware Information
Action To display the MCS hardware information, use the following CLI command:
user@host> show chassis hardware
Sample Output
user@host>
show chassis hardware
Hardware inventory:
Item Version Part number Serial number Description
Chassis M40e
[...Output truncated...]
Routing Engine 0 d8000007c8460a01 RE-2.0
MCS 0 REV 11 710-001226 AS4709
[...Output truncated...]
