Getting SFM Hardware Information ! 357
Chapter 26: Monitoring the SFMs
Getting SFM Hardware Information
Steps To Take To get the hardware information you need to return a failed SFM, follow these steps:
1. Display SFM Hardware Information on page 357
2. Locate the SFM Serial Number ID Label on page 357
Step 1: Display SFM Hardware Information
Action To display the SFM hardware information, use the following CLI command:
user@host> show chassis hardware
Sample Output
user@host>
show chassis hardware
Item Version Part number Serial number Description
Chassis 20079 M160
[...Output truncated...]
SFM 0 SPP REV 04 710-001228 AA2860
SFM 0 SPR REV 01 710-001224 AB0139 Internet Processor I
SFM 1 SPP REV 04 710-001228 AA2859
SFM 1 SPR REV 02 710-001224 AA9861 Internet Processor I
SFM 2 SPP REV 06 710-001228 AB3082
SFM 2 SPR
SFM 3 SPP REV 04 710-001228 AA1998
SFM 3 SPR REV 01 710-001224 AB0137 Internet Processor I
[...Output truncated...]
What it Means The command output displays the SFM slot number and SFM serial component
(SPP and SPR) card names, SFM revision level, part number, serial number, and
description.
Step 2: Locate the SFM Serial Number ID Label
Action To locate the SFM serial number ID label, look on the left side of the SFM top panel
(see Figure 147).
Figure 147: SFM Serial Number ID Label
1618
Serial number ID label
