Getting SCB Hardware Information ! 401
Chapter 30: Monitoring the SCB
6. Replace the SCB with one that you know works.
7. Grasp the front of the SCB card carrier with both hands and align the back of
the working SCB card carrier with the slide guides on the chassis.
8. Slide the SCB card carrier all the way into the card cage until it contacts the
backplane.
9. Flip the extractor clips, located on the top and bottom of the card carrier,
towards each other to lodge the SCB in place.
10. Tighten the thumbscrews on the card carrier to seat the SCB.
Getting SCB Hardware Information
Steps To Take To obtain SCB hardware information, follow these steps:
1. Display the SCB Hardware Information on page 401
2. Locate the SCB Serial Number ID Label on page 402
3. Display the SCB Firmware Version on page 402
Step 1: Display the SCB Hardware Information
Action To display the SCB hardware information, use the following CLI command:
user@host> show chassis hardware
Sample Output
user@host>
show chassis hardware
Hardware inventory:
Item Version Part number Serial number Description
Chassis 00291 M40
Backplane REV 10 710-000073 AA2220
Power Supply A Rev A1 740-000234 000134 AC
Maxicab REV 07 710-000229 AA6957
Minicab REV 03 710-000482 AA3324
Display REV 07 710-000150 AA7798
Routing Engine RE-1.0
SCB REV 11 710-000075 AA7244 Internet Processor I
[...Output truncated...]
What It Means The command output displays the SCB version level, part number, serial number,
and description.
NOTE: To seat the SCB properly, be sure to tighten the screws securely. If the SCB is
not seated properly, it will not function.
