Performing a Swap Test on an HCM ! 629
Chapter 48: Monitoring Redundant HCMs
Uptime 2 hours, 13 minutes, 57 seconds
Routing Engine status:
Slot 1:
Current state Master
Election priority Backup (default)
Temperature 33 degrees C / 91 degrees F
CPU temperature 29 degrees C / 84 degrees F
DRAM 2048 MB
Memory utilization 12 percent
CPU utilization:
User 0 percent
Background 0 percent
Kernel 3 percent
Interrupt 0 percent
Idle 97 percent
Model RE-3.0
Serial ID P10865701255
Start time 2005-02-03 03:13:39 UTC
Uptime 13 days, 21 hours, 12 minutes, 35 seconds
Load averages: 1 minute 5 minute 15 minute
0.00 0.03 0.01
What It Means The Routing Engine in slot RE0 and companion HCM in slot HCM0 are backup. The
Routing Engine in slot
RE1 and companion HCM in slot HCM1 are master.
Alternative Method To verify an HCM failure, you can also use the following CLI command:
user@host> show chassis environment hcm
Sample Output
user@host>
show chassis environment hcm
HCM 0 status:
State Offline
FPGA Revision 27
HCM 1 status:
State Online Master
FPGA Revision 27
What It Means The HCM in slot HCM0 is offline. The HCM in slot HCM1 has taken over as master.
Performing a Swap Test on an HCM
Action To perform a swap test on a HCM, see “Performing A Swap Test” on page 438.
Returning an HCM
Action To return an HCM, find the serial number ID label (see “Locate the HCM Serial
Number ID Label” on page 442), then follow the procedure as described in the M10i
Internet Router Hardware Guide, or see “Return the Failed Component” on page 86.
