JUNOS Internet Software Network Operations Guide: Hardware
446 ! Displaying FIC Alarms
Step 3: Check FIC LEDs
Figure 104 describes the FIC interface LEDs located on the FIC faceplate.
Table 104: Table 6: FIC Interface LEDs
Displaying FIC Alarms
Steps To Take To determine whether the FIC is offline, follow these steps:
1. Display the FIC Status on page 446
2. Display FIC Errors In the nmessages Log File on page 446
3. Display FIC Errors In the chassisd Log File on page 447
Step 1: Display the FIC Status
Action To view the FIC status, use the following CLI command:
user@host> show chassis pic pic-slot 3 fpc-slot 1
Sample Output
user@host>
show chassis pic pic-slot 3 fpc-slot 1
PIC fpc slot 1 pic slot 3 information:
State Offline
What It Means The FIC in fpc slot 1 pic slot 3 is offline.
Step 2: Display FIC Errors In the nmessages Log File
Action To display the FIC errors recorded in the messages log file, use the following CLI
command:
user@host> show log messages | match PIC 3
Sample Output
user@host>
show log messages | match PIC 3 in FPC 1
Feb 22 05:50:58 noah chassisd[4738]: CHASSISD_PIC_OFFLINE_NOTICE: Taking PIC 3
in FPC 1 offline: Offlined by cli command
Feb 22 05:50:58 noah cfeb CMFPC: Offline CMD request for PIC 1/3
Feb 22 05:50:58 noah chassisd[4738]: CHASSISD_IFDEV_DETACH_PIC:
ifdev_detach_pic(1/3)
Feb 22 05:50:58 noah chassisd[4738]: CHASSISD_SNMP_TRAP9: SNMP trap generated:
FRU power off (jnxFruContentsIndex 8, jnxFruL1Index 2, jnxFruL2Index 4,
jnxFruL3Index 0, jnxFruName PIC: 2x F/E, 100 BASE-TX @ 1/3/*, jnxFruType 11,
jnxFruSlot 2, jnxFruOfflineReason 7, jnxFruLastPowerOff 30713054,
jnxFruLastPowerOn 407915)
Label Color State Description
LINK
Green On steadily The port is online.
ACTIVITY Green Blinking The port is receiving data.
Off The port might be on, but is not receiving
data.
