JUNOS Internet Software Network Operations Guide: Hardware
12 ! M10i Router Components
The M10i router provides a maximum aggregate throughput of 12.8 gigabits per
second (Gbps). Control operations in the router are performed by the Routing
Engine, which runs JUNOS software to handle routing protocols, traffic engineering,
policy, policing, monitoring, and configuration management. Forwarding operations
in the router are performed by the Packet Forwarding Engine.
M10i Router Components
Table 5 lists the major M10i router components and characteristics.
Table 5: M10i Router Major Hardware Components
Component Quantity Function Redundant
Field-
Replaceable
Offline
Button
CFEB 1 or 2 Provides route lookup, filtering, and
switching on incoming data packets;
directs outbound packets to the
appropriate FPC for transmission to the
network
Yes Hot-pluggable Yes
Cooling system 2 fan trays
(8 fans)
Cools router components Yes Hot-removable,
hot-insertable
–
FPC 2 House the PICs that connect the router to
network media
–Built-in–
HCM 2 Works with a companion Routing Engine
to provide control and monitoring
functions for router components; displays
alarm status; takes PICs online and offline
Hot-pluggable –
PIC 1–8 Provides interfaces to various network
media; receives incoming packets from
the network and transmits outgoing
packets to the network, performing
framing and line-speed signaling for their
media type; encapsulates outgoing
packets received from the FPCs before
transmitting them.
– Hot-removable,
hot-insertable
Yes
(On the
HCM)
Power supply 1–4
AC or DC
Distributes needed voltages to
components
Yes Hot-removable,
hot-insertable
Yes
SFP Fiber-optic transceivers that connect to
PICs
– Hot-removable,
hot-insertable
–
Routing Engine 1 or 2 Runs the JUNOS software; maintains the
routing tables, manages the routing
protocols used on the router, controls the
router’s interfaces, controls some chassis
components, and provides the interface
for system management and user access
to the router
Yes Hot-pluggable Yes
