JUNOS Internet Software Network Operations Guide: Hardware
228 ! Understanding Power Supplies
T320 Router Power Supplies
Figure 93 shows the T320 router power supplies and where they are installed in the
chassis.
Figure 93: T320 Router Power Supplies Location
NOTE: Each power supply must be connected to a dedicated AC power feed and a
dedicated 15 A (250 VAC) circuit breaker.
T320 router rear
DC power supply
Power supplies
g002106
