Verifying PIC Failure ! 193
Chapter 16: Monitoring PICs
For M320 routers, the serial number ID label is located on the right side of the PIC
(see Figure 68) when the PIC is vertically oriented (as it would be installed in the
router). The exact location may be slightly different on different PICs, depending on
the placement of components on the PIC board.
Figure 68: M320 Router Serial Number ID Label on PIC
Tunnel Services
STATUS
OFFLINE
1580
Serial number ID label
AA1234
