JUNOS Internet Software Network Operations Guide: Hardware
266 ! Understanding the Cooling System
Figure 120 shows the T640 routing node cooling system components.
Figure 120: T640 Routing Node Cooling System Components
See Also
“Monitoring Power Supplies” on page 217
g
003263
Front top
fan tray
T640 front T640 rear
Front bottom
fan tray
Front
air filter
Air intake
Air exhaust
Rear fan tray
Rear
air filter
