328 ! Understanding the SIBs
Figure 136 shows the location of the SIBs on the M320 router, T320 router, and the
T640 routing node.
Figure 136: M320 Router, T320 Router, and T640 Routing Node SIB Location
SIBs
SIBs
SIB0
SIB1
SIB2
SIB0
SIB1
SIB2
SIB3
SIB4
T320 rear
M320 rear
T640 rear
