530 ! Understanding Redundant Cooling System Components
Figure 215 shows the M40 router cooling system impeller trays.
Figure 215: M40 Router Impeller Trays
Figure 216 shows the M40 router air filter and fan tray.
Figure 216: M40 Router Air Filter and Fan Tray
1773
Lower
impeller tray
Upper
impeller tray
Front Rear
1772
Air filter
(behind cover)
Rear
fan tray
R
Front Rear
