JUNOS Internet Software Network Operations Guide: Hardware
532 ! Understanding Redundant Cooling System Components
Figure 218 shows the M40e and M160 router cooling system components.
Figure 218: M40e and M160 Router Cooling System Components
See Also
! Monitoring Power Supplies on page 217
1775
Air filter
Air filter cover
M40e and M160 router front
Fan tray
Front right fan
Front left
fan
Rear right
fan
Rear left
fan
Front upper
Impeller assembly
R
M40e router rear M160 router rear
M40e and M160 router rear
Rear lower
Impeller assembly
Rear upper
Impeller assembly
Rear upper
Impeller assembly
M40e and M160 router front
