Rigging work
11.8 Outrigger operation
Operating Instructions GMK5250L 3 302 633 en 11 - 47
27.09.2017
With the hand-
held control
The hand-held control must be connected to the carrier.
• Connect the hand-held control to the
required socket (1) or (2).
Information on connecting;
à Connecting the
hand-held control
, p. 11 - 22.
Start the engine
• Press the button (1) – the engine starts; à p. 9 - 8.
Pre-select high-speed mode/normal speed
• Press the button (2).
– Lamp (1) lights up – high-speed mode pre-selected,
– Lamp (1) goes out – normal speed pre-selected.
s
1 For the right-hand outrigger beam
2 For the left-hand outrigger beam
