ID Index Name Unit Description
2682 0 CON_PRC_StatWord Processcontrol:Statusword
2683 0 CON_PRC_REFSEL Selectionofsourceforreferencevalue
2684 0 CON_PRC_REFVAL_
User
Processcontroluserreferencevalue
Table 7.37: “Process controller” parameters (continue)
7.10.5Scopesignals
ID Index Parameter name Unit Function
2675 0 CON_PRC_Cdiff_ Controldifferenceoftheprocesscontroller
2666 0 CON_PRC_RefVal Scaledprocesscontrollerreference
2673 0 CON_PRC_Raw_ActVal Actualvalueoftheselectedactualvaluesource
2674 0 CON_RPC_Actval Momentaryactualvalueoftheprocess
controller;afterfilteringandscaling
2676 0 CCON_PRC_Outval Processcontrollercontrolvariable
Table 7.38: Parameters relevant for visualizing the process control circuit in the
scope
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
159
7 Control
