8.10Touchprobe
Using the touch probe inputs, touch probe functions can be performed. To do this,
P106[0] - MPRO_INPUT_FS_ISD05 and P107[0] - MPRO_INPUT_FS_ISD06
must be used to set digital inputs ISD05 and ISD06 to "PROBE(15) = Touch probe
(only ISD05/06)" (see Section "Digital Inputs" on page 232). HTL encoders can be
evaluated or pulse counters implemented using the MSD PLC.
The touch probe can be triggered with P240 - MPRO_TP_Ctrl. This enables
triggering on a positive or negative edge, or on both edges, of the signal detected on
the touch probe inputs. After the measurement, the parameter jumps back to the
value "NONE (0)" and the latch position is mapped in the corresponding subindex of
parameter P 241 - MPRO_TP_Position. A continuous touch probe mode is not
possible at present, so the touch probe has to be reactivated after the measurement.
P1402 - MPRO_TP_Channel can be used to select various positions as actual
value sources for the latch position for the touch probe functionality.
The following table provides an overview of the available settings. The counters are
accessed via the MSD PLC or a bus system.
ID Index Name / Setting Unit Description
240 MPRO_TP_Ctrl Touchprobe:Controlword
Thefollowing
settingsapplyto
indexes0–2
0 NONE(0)=Nofunction
1 POS(1)=Positiveedge
2 NEG(2)=Negativeedge
3 BOTH(3)=Bothedges
240 0 MPRO_TP_Ctrl
240 1 MPRO_TP_Ctrl
240 2 MPRO_TP_Ctrl
241 MPRO_TP_Position Probe:Pos.high/lowedgeofTP0/1,encoder
zeropulse
Table 8.29: “Touch probe” parameters
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
217
8 Motion profile
ID Index Name / Setting Unit Description
241 0 MPRO_TP_Position mDegree
241 1 MPRO_TP_Position mDegree
241 2 MPRO_TP_Position mDegree
241 3 MPRO_TP_Position mDegree
241 4 MPRO_TP_Position mDegree
1400 0 MPRO_TP_Config Touchprobe:Configuration
TP_TP(0) TP0,TP1touchprobe
AB(1) TP0,TP1asencoder,A/Basquadrature
counting
PD_UP(2) TP0,TP1asencoder,pulse(TP0)/direction
(TP1),countupondirectionhigh
PD_DOWN(3) TP0,TP1asencoder,pulse(TP0)/direction
(TP1),countdownondirectionhigh
PC_PC(4) TP0pulsecounter,TP1pulsecounter
PC_TP(5) TP0pulsecounter,TP1touchprobe
TP_PC(6) TP1touchprobe,TP0pulsecounter
ENC_ENC(7) TP0encodercounter,TP1encodercounter
ENC_TP(8) TP0encodercounter,TP1touchprobe
TP_ENC(9) TP0touchprobe,TP1encodercounter
1402 MPRO_TP_Channel Touchprobe:Configurationprobechannel
Thefollowing
settingsapplyto
indexes0–2
0 ACTPOS(0)=Actualpositioninuserunits
1 ACTPOSINC(1)=Actualpositionin
increments
2 MASTERPOS(2)=Masterpositionin
increments
3 ENCPOS_CH1(3)=Encoderposition
Channel1
4 ENCPOS_CH1_INC(4)=Encoderposition
Channel1inincrements
5 ENCPOS_CH2(5)=Encoderposition
Channel2
6 ENCPOS_CH2_INC(6)=Encoderposition
Channel2inincrements
7 ENCPOS_CH3(7)=Encoderposition
