5Motor
Chapter overview
Pictogram
Navigation ►Projecttree►DriveSettings►Motor
Brief description Thefollowingchapterdescribesthestepsusedtocalculate
parametersfor,identifyandconfiguremotors,aswellastheir
protectionmechanismsandbrake.
Contents
5.1 Motor configuration data 31
5.2 Synchronous motor 32
5.3 Linear synchronous motor 35
5.4 Asynchronous motor 37
5.5 Motor protection 39
5.6 Motor identification 43
5.7 Support for motor filters when using PMSM motors 45
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
31
5 Motor
5.1Motorconfigurationdata
Fig. 5.1: "Motor data and control settings" screen
Each motor can only be operated if its field model and the control parameters are
correctly set. Using the standard motors and encoders from the Moog motors
catalog, a system can be commissioned and put into operation very quickly and
easily. Third-party motors can of course be used as well. As the field models of those
motors are not known, the motor must be identified by type or calculated. The
selection is made with the preceding “Motor data and control settings” screen.
