6.7.2X8absolutevalueinterfaces
The following absolute value interfaces will be available on encoder channel Ch3
depending on the X8 option being used.
 CyclicalSin/CoswithSSIone-timereadingviaX8option:SINCOS_V2(10)-
2ndSin/Cosencoder(V2)
 CyclicalSin/CoswithEnDatone-timereadingviaX8option:SINCOS_V2(10)
-2ndSin/Cosencoder(V2)
 CyclicalSSIviaX8options:SINCOS_V2(10)-2ndSin/Cosencoder(V2)or
SSI_ECSIM(3)-SSIencodersimulation
 CyclicalEnDatviaX8option:SINCOS_V2(10)-2ndSin/Cosencoder(V2)
See also table in Section "Channel 3: Interface X8 (optional)" on page 74 as well.
They can be selected with P507[0] - ENC_CH3_Sel and P570[0] - ENC_CH3_Abs.
For details, see Section "Main parameters for encoder channel Ch3" on page 78.
6.7.3EnDat(cyclical)X8
Ch3: ENDAT(4) - Cyclical EnDat (2.1 or 2.2)
As the EnDat functionality of the parameters for encoder channel Ch3 is
predominantly identical to that of the parameters for encoder channel Ch1, it is
recommended to read the description for the Ch1 encoder channel parameters (see
Section "EnDat (cyclical)X7" on page 58).
The software versions required to run the EnDat interface are the standard software
versions for the MSD Servo Drive and MSDSingle-Axis Servo Drive Compact.
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
80
6 Encoder
NOTE

Pleasenote thelimitations thatapply whenrunningEnDatand
SSI encoders (see Section "Limiting for EnDat and SSI" on
page50).
ID Index Name Unit Description
507 0 ENC_CH3_Sel=4 =ENDAT(4)
573 0 ENC_CH3_MultiT NumberofMultiTurnbits(absoluteencoder)
574 0 ENC_CH3_SingleT NumberofSingleTurnbits(absoluteencoder)
584 0 ENC_CH3_MTBase Definitionofpointofdiscontinuityinmulti-turn
range
585 0 ENC_CH3_MTEnable 1:Usemulti-turnencoderassingle-turnencoder
636 0 ENC_CH3_CycleCount Positionencodersamplingcycle(nx125µsec)
600 0 ENC_CH3_Position inc Positionencoderchannel3
583 0 ENC_CH3_
DigitalResolution
nm Lengthofoneincrement(linearabsoluteencoder)
640 0..29 ENC_ENDAT EnDatadditional(additionalinformation)
Table 6.22: Channel 3 encoder configuration (X8) - EnDat (cyclical) parameters
6.7.4HallsensorX8
Encoder channel Ch3 does not support Hall effect sensors!
