4 Power Stage
4.1Powerstagesettings
Fig. 4.1: AC device “Power stage configuration” screen
The power stages of the servo drive can be operated with different voltages and
switching frequencies. The list boxes in the dialog box are used to adapt the power
stage to the application conditions.
NOTE
 Anychangestoparametersmustbesavedinthedevice.
 Thesettingisonlyappliedonthedeviceafterapoweroff/on
cycle.
 Ifthepowerstageparametersarechanged,theratedcurrents,
overloadvaluesandbrakechopperthresholdsmayalsochange.
