Moog MSD Servo Drive Series

15Manualmode
Chapter overview
Pictogram
Navigation ►Projecttree►DriveSettings►Manualmode
Brief description Thischapterdescribestheconfigurationandcontroloptions
forthe“Manualmode”window.
Contents
15.1 Manual mode window
302
15.2 Manual mode control status
306
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
302
15 Manual mode
15.1Manualmodewindow
NOTE
 Read,complywithandconfirmthesafetyprompt!
 Assoonasthe“Manualmode”windowopens,allunrelated
devicesettingswillbedisabled.Thesedevicesettingswillbere-
enabledafterthe“Manualmode”windowisclosed.
The manual mode window will appear, but be disabled at first. Once you click on the
“Activate manual mode” button, a safety prompt that needs to be confirmed will
appear.
Fig. 15.1: Safety information
