Moog MSD Servo Drive Series User Manual

NOTE
 Additionaltimesforthetypicalcontactchatteronacontactormust
betakenintoaccountwhenspecifyingthetimefortimerP 148[0] -
MPRO_DRVCOM_ENMO_Time.Theymaybeseveralhundred
ms,dependingoncontactor.
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
243
9 Input/Output settings
9.4Analoginputs
Fig. 9.8: “Function selector of the analog inputs” dialog box
9.4.1Standardanaloginputs
 Thereisaselectorthatcanbeusedtoassignafunctiontoeachanalog
standardinput(P 109[0] - MPRO_INPUT_FS_ISA00andP 110[0] - MPRO_
INPUT_FS_ISA01).
 Certainfunctionswillonlybeavailablewithspecificfunctionpackages.
 Dependingontheconfiguredfunction,the“Options...”buttonmaybecome
enabled.Ifitis,thisbuttoncanbeusedtoswitchtoadifferentscreendirectly
anddefinethefunction’sexactbehaviourthere.
 Everyanaloginputcanbesmoothedwithafreelyconfigurablefiltertime
(P 405[0] - CON_ANA_Filt0andP 406[0] - CON_ANA_Filt1).
 P 427[0] - CON_ANA_CalibZerocanbeusedtotriggerazerocorrection
routineforbothanaloginputs.Ifyouusethisroutine,theremustnotbeany
voltageattheinputs.
