Moog MSD Servo Drive Series User Manual

3.4Encoder
Fig. 3.6: “Initial commissioning - Encoder selection” dialog box
 Thereisadatabaseavailableforcommissioningtheencoder.Thisdatabase
canbeusedtoselectfromalargenumberofstandardmodels.

Ifyouareunabletofindyourencodermodelorwanttoconfigureadditional
settings,clickonthe"Settings..."button.FordetailsseeSection "Encoder
selection"onpage51
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
24
3 Initial commissioning
3.5Control
Fig. 3.7: “Initial Commissioning - Control” dialog box
 Youcanusethisscreentoselectthecontrolmodeforthedevice.

Todeterminethesystem’sinertiaandconfigurepositionandspeedcontrol
settings,clickonthe"Basic settings"button.FordetailsseeSection"Basic
settings"onpage107.

Toaccessthe“Control”screen,clickonthe"Advanced >>"button.For
detailsseeSection"Basicsettings"onpage107.
