13Technologyoptions(X8)
Chapter overview
Pictogram
Navigation ►Projecttree►DriveSettings►Technologyoptions(X8)
Brief description Thischapterprovidesinformationonthetechnologyoptions
availableforconnectorX8.
Contents
13.1 Selection of modules
296
13.2 Second Sin/Cos encoder
297
13.3 Sin/Cos encoder
297
13.4 TTL with encoder simulation
298
13.5 SSI encoder simulation
298
13.6 TwinSync
299
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
296
13 Technology options (X8)
13.1Selection of modules
Fig. 13.1: “Technology options (X8) settings” dialog box
Option X8 (available only from the factory; cannot be retrofitted) supports the
following options:
Sin/Cosmodule(see Section"Channel3:InterfaceX8 (optional)"on
page74)
TTLencoder/simulation(see Section"TTLwithencodersimulation"on page
298)
TTLencoderwithcommutationsignals
SSImodule(see Section"SSIencodersimulation"onpage298)
TwinSyncmodule(see Section"TwinSync"onpage299)
For the encoder types that can be evaluated, see Section "Channel 3: Interface X8
(optional)" on page 74 as well.
