P No. Index P Name / Setting Unit Function
732 MON_MotorPTC Selectionofsensortype
0 Type
Off(0) Nomotortemperaturesensor
KTY(1) KTY84-130Sensor
PTC(2) PTCsensor(three)withshortcircuitmonitoring
below50Ohmorhardwaredetection
TSS(3) Switch(Klixon)
PTC1(4) PTCsensor(one)withoutshortcircuit
monitoring
PT100(5) PTC100inlinewithDINEN60751
NTC220(6) NTCSensor220kOhm
1)
NTC1000(7) NTCSensor1000kOhm
NTC_K227(8) NTCSensorK22732kOhm
KTY83-110(9) KTY83-110Sensor
NTC50(10) NTCsensor50kOhm
NTC10(11) NTCSensor10kOhm
PTC2(12) PTCsensor(simple)withshortcircuit
monitoringunder5ohms
PT1000(13) PT1000Sensor
1 Contact Terminationvariant
X5(0) ConnectionofthesensortoterminalX5
X6/7(1) Sensorconnectionisroutedinencodercable
X5_X6/7(2) Useofbothinputspossible
X8(3) X8connectortemperaturesensor(techopt
module)
X5_X8(4) X5andX8connectortemperaturesensor(tech
optmodule)
2 Typeextended
Off(0) Nomotortemperaturesensor
KTY(1) KTY84-130Sensor
PTC(2) PTCsensor(three)withshortcircuitmonitoring
below50Ohmorhardwaredetection
TSS(3) Switch(Klixon)
PTC1(4) PTCsensor(one)withoutshortcircuit
monitoring
Table 5.7: “Temperature monitoring” parameters (continued)
MOOG
ID
No.: CB40859-001 Date: 02/2018
MSD Servo Drive- Device Help
40
5 Motor
P No. Index P Name / Setting Unit Function
PT100(5) PTC100inlinewithDINEN60751
NTC220(6) NTCSensor220kOhm
1)
NTC1000(7) NTCSensor1000kOhm
NTC_K227(8) NTCSensorK22732kOhm
KTY83-110(9) KTY83-110Sensor
NTC50(10) NTCsensor50kOhm
NTC10(11) NTCSensor10kOhm
PTC2(12) PTCsensor(simple)withshortcircuit
monitoringunder5Ohm
PT1000(13) PT1000Sensor
733 MON_MotorI2t I
2
tcharacteristicsetting
0 Inom % Ratedcurrentofthemotor
1 I0 % Firstcurrentinterpolationpointofmotor
protectioncharacteristic:Maximum
permissiblestandstillcurrent
2 I1 % Secondcurrentinterpolationpointofmotor
protectioncharacteristicreferredtomaximum
characteristiccurrent
3 F1 Hz Firstfrequencyinterpolationpointofmotor
protectioncharacteristic
4 FNom Hz Ratedfrequency
5 IMax % Maximumoverloadcurrentreferredtorated
motorcurrent
6 Time s Timeforwhichthemaximumcurrentmaybe
connected
7 Ttherm s Setthermaltimeconstantinseconds
735 0 MON_MotorI2tType Motorprotectionmode
Off(-1) Protectiondisabled
FREQU(0) Motorfrequency-dependentevaluationi(f),
defaultsetting
THERM(1) Evaluationwiththermaltimeconstanti
Tth
.The
thermaltimeconstantissetwithP 733[7]in
[s].Duetomeasuringtolerances,the
shutdownthresholdis110%oftheratedvalue.
Table 5.7: “Temperature monitoring” parameters (continued)
