Omron F3SG-SRB Series User Manual

140
Chapter3 Backup/Restoration
F3SG-SR
User’s Manual
Setting with Intelligent Tap
If the sensor configuration (model and cascading) in the Intelligent Tap corresponds with that of the
actual one, the Restoration is automatically performed.(1)
If the sensor configurations differ only in the number of beams, you can forcibly perform the
Restoration with the Push Switch.(2)
If the sensor configuration of other than the number of beams is not the same, perform the Backup of
the connected F3SG-SR and then perform the Restoration again.
After the Restoration is performed, verify that the F3SG-SR operates with intended settings before using the F3SG-SR.
 LED indication during Restoration
Function Indicator
Mode State
IN
(Yellow)
OUT
(Green/Red)
IO-Link
(Green)
ERR
(Red)
Restoration
Transitioning modes
--
Waiting for Push Switch operation
Transferring data
Waiting for restart after Restoration
Waiting for restart due to
unenforceable condition
Waiting for restart due to
communication error
㻳㼞㼑㼑㼚
㻳㼞㼑㼑㼚
㻳㼞㼑㼑㼚
㻳㼞㼑㼑㼚
㻳㼞㼑㼑㼚
㻳㼞㼑㼑㼚
Illuminated OFF
Fast
blinking
Slow
blinking
Fast blinking
Slow blinking
0.25 s
0.5 s
1.0 s
2.0 s
