Page #183 background imageLoading...
Page #183 background image
155
F3SG-SR
User’s Manual
Chapter3 IO-Link
Setting with Intelligent Tap
E
70 1 Synchronization
method setting
R 1 byte 0: Optical sync. Scan code A
1: Optical sync. Scan code B
2: Wired sync.
3: Reserved.
2 External device
monitor setting
R 1 byte 1: Enable , 0: Disable
3 Interlock / Pre-
Reset / PSDI
setting
R 1 byte 0: Auto reset (both start and re-start interlock are disabled)
1: Start interlock is enabled.
2: Re-start interlock is enabled.
3: Manual reset (both start and re-start interlock are
enabled)
4: Pre-Reset is enabled.
5: PSDI single break
6: PSDI double break
The others: Reserved.
4 Blanking setting R 1 byte 1: One of Fixed Blanking or Floating Blanking and Warning
zone setting is enabled.
0: Fixed Blanking, Floating Blanking and Warning zone
setting are disabled.
5 PNP / NPN setting R 1 byte 1: PNP setting
0: NPN setting
6 Dip switch setting R 1 byte 1: Enable
0: Disable (setting is done by Tool)
7 Muting status R 1 byte 1: Under the MUTING state
0: The other
8 Override status R 1 byte 1: Under the OVERRIDE state
0: The other
9 Muting sequence
error status
R 1 byte 1: Muting setting is active and sequence error occurs.
2: The other
10 Safety output status R 1 byte 1: ON
0: OFF
11 Blanking bream
unblocked
information
R 1 byte 1: When Fixed-Blanking or Floating Blanking beams are
unblocked
0: The other
12 Push switch status R 1 byte 1: ON
0: OFF
71
(Primary
sensor
Receiver)
0 Receiving light level R 232 bytes 1byte x 232 beams
The incident light level data of each beam is output in 0 to
255 (8 bits) every beam (1 byte).
0 if SLC is not connected
72
(Secondary
sensor 1
Receiver)
0 Receiving light level R 232 bytes 1byte x 232 beams
The incident light level data of each beam is output in 0 to
255 (8 bits) every beam (1 byte).
0 if SLC is not connected
73
(Secondary
sensor 2
Receiver)
0 Receiving light level R 232 bytes 1byte x 232 beams
The incident light level data of each beam is output in 0 to
255 (8 bits) every beam (1 byte).
0 if SLC is not connected
80 0 Error code of
Intelligent Tap
R 48 bytes
(8 bytes
x 6)
Error code data is output in 8 bytes.
In order from upper to lower
1 byte: Error code
4 bytes: Power-ON Time (1 count every 15 minutes)
3 bytes: Data for inquiry*
Latest 6 records can be got.
* Please use the data for your inquiry.
Index Sub-Index Name R/W Length Setting contents
