Chapter3 IO-Link
F3SG-SR
User’s Manual
Setting with Intelligent Tap
Refer to 8-1-2-2. Troubleshooting for more information on error codes and error descriptions.
81
(Primary
sensor
Receiver)
0 Error code R 32 bytes
(8 bytes
x 4)
Error code data is output in 8 bytes.
In order from upper to lower
1 byte: Error code
4 bytes: Power-ON Time (1 count every 15 minutes)
3 bytes: Data for inquiry*
Latest 4 records can be got.
* Please use the data for your inquiry.
0 if SLC is not connected
82
(Secondary
sensor 1
Receiver)
0 Error code R 32 bytes
(8 bytes
x 4)
Error code data is output in 8 bytes.
In order from upper to lower
1 byte: Error code
4 bytes: Power-ON Time (1 count every 15 minutes)
3 bytes: Data for inquiry*
Latest 4 records can be got.
* Please use the data for your inquiry.
0 if SLC is not connected
83
(Secondary
sensor 2
Receiver)
0 Error code R 32 bytes
(8 bytes
x 4)
Error code data is output in 8 bytes.
In order from upper to lower
1 byte: Error code
4 bytes: Power-ON Time (1 count every 15 minutes)
3 bytes: Data for inquiry*
Latest 4 records can be got.
* Please use the data for your inquiry.
0 if SLC is not connected
84
(Primary
sensor
Emitter)
0 Error code R 32 bytes
(8 bytes
x 4)
Error code data is output in 8 bytes.
In order from upper to lower
1 byte: Error code
4 bytes: Power-ON Time (1 count every 15 minutes)
3 bytes: Data for inquiry*
Latest 4 records can be got.
* Please use the data for your inquiry.
0 if SLC is not connected
85
(Secondary
sensor 1
Emitter)
0 Error code R 32 bytes
(8 bytes
x 4)
Error code data is output in 8 bytes.
In order from upper to lower
1 byte: Error code
4 bytes: Power-ON Time (1 count every 15 minutes)
3 bytes: Data for inquiry*
Latest 4 records can be got.
* Please use the data for your inquiry.
0 if SLC is not connected
86
(Secondary
sensor 2
Emitter)
0 Error code R 32 bytes
(8 bytes
x 4)
Error code data is output in 8 bytes.
In order from upper to lower
1 byte: Error code
4 bytes: Power-ON Time (1 count every 15 minutes)
3 bytes: Data for inquiry*
Latest 4 records can be got.
* Please use the data for your inquiry.
0 if SLC is not connected
160 0 Operation Time
Operation time
period
R 4 bytes The Power-ON Time of Intelligent Tap (1 count every 1
hours)
