167
F3SG-SR
User’s Manual
Chapter4 Overview and Specifications
Setting with SD Manager 3
E
5. The searched devices are displayed like the screen below, so click the device connected.
For the device names of the Intelligent Tap connected with the Bluetooth
®
communication unit and
F3SG-SR, the serial number and model name of the F3SG-SR are displayed. For the F3SG-SR in
cascade connection, the serial number and model name of the primary sensor are displayed.
When pairing with more than one device, adding a device must be carried out one by one.
6. The screen below is displayed and a necessary device driver is installed.
7. Confirm that the installation of the device driver is fully completed. When the installation is complete,
the message shown below is displayed.
Now the pairing is complete.
To Next Page
