Omron F3SG-SRB Series User Manual

211
F3SG-SR
User’s Manual
Chapter4 Changing Settings with SD Manager 3
Setting with SD Manager 3
E
 Muting Time Information Setup Procedure
6-1 Enter [Muting Time Information] according to the setup state (No. 1).
6-2 Click [Installation Position Check] button (No. 2).
6-3 Enter [Input Information] according to the setup state (No. 3).
6-4 Click [Evaluation] to confirm the integrity of the entered condition (No. 5). The result is displayed in
area 4.
If the result is Installation NG, review the entered condition above.
6-5 Click [Close] button (No. 7).
For more information on Muting Time Information (how to optimize T1), refer to 4-4-2. Muting Statistics Information.
