Chapter1 Ratings and Specifications
F3SG-SR
User’s Manual
Overview and Specifications
Input voltage TEST Light emission stops when connected to 24 VDC
ON voltage: Vs-3 V to Vs (short circuit current: approx. 5.0 mA) *
OFF voltage: 0 V to 1/2 Vs, or open (short circuit current: approx. 6.0 mA) *
Light emission stops when connected to 0 V
ON voltage: 0 to 3 V (short circuit current: approx. 6.0 mA)
OFF voltage: 1/2 Vs to Vs, or open (short circuit current: approx. 5.0 mA) *
OPERATING
RANGE
SELECT
INPUT
Long: 12 V to Vs (short circuit current: approx. 4.2 mA) * or open
Short: 0 to 3 V (short circuit current: approx. 4.2 mA)
RESET/EDM PNP
ON voltage: Vs-3 V to Vs (short circuit current: approx. 9.5 mA) *
OFF voltage: 0 V to 1/2 Vs, or open (short circuit current: approx. 13.0 mA) *
NPN
ON voltage: 0 to 3 V (short circuit current: approx. 13.0 mA)
OFF voltage: 1/2 Vs to Vs, or open (short circuit current: approx. 9.5 mA) *
MUTE A/B ,
PRE-RESET,
PSDI
PNP
ON voltage: Vs-3 V to Vs (short circuit current: approx. 4.5 mA) *
OFF voltage: 0 V to 1/2 Vs, or open (short circuit current: approx. 7.0 mA) *
NPN
ON voltage: 0 to 3 V (short circuit current: approx. 7.0 mA)
OFF voltage: 1/2 Vs to Vs, or open (short circuit current: approx. 4.5 mA) *
*The Vs indicates a supply voltage value in your environment.
Overvoltage category
(IEC 60664-1)
II
Indicators
See  F3SG-SR Series for more information.
Protective circuit Output short-circuit protection
Insulation resistance 20 M or higher (500 VDC megger)
Dielectric strength 1,000 VAC, 50/60 Hz (1 min)
Functional Mutual interference prevention Optical synchronization by Scan Code: in up to 2 sets
Wired synchronization: in up to 3 sets
See 5-1-4. Mutual Interference Prevention for more information.
Cascade connection Number of cascaded segments: 3 max.
Total number of beams: 255 max.
Test function Self-test (at power-on, and during operation)
External test (light emission stop function by test input)
Safety-related functions Interlock
External Device Monitoring (EDM)
Pre-Reset
PSDI
Fixed Blanking/Floating Blanking
Reduced Resolution
Muting/Override
Mutual Interference Prevention
PNP/NPN Selection
Response Time Adjustment
See Chapter 2 System Operation and Functions and Chapter 3 Setting with
Intelligent Tap for more information.
Model
F3SG-SRA-14
F3SG-SRB-14
F3SG-SRA-25
F3SG-SRB-25
F3SG-SRA-45
F3SG-SRB-45
F3SG-SRA-85
F3SG-SRB-85
