Omron F3SG-SRB Series User Manual

15
F3SG-SR
User’s Manual
Chapter1 Ratings and Specifications
Overview and Specifications
E
Environmental Ambient
temperature
Operating -30 to 55 °C (non-icing)
Storage -30 to 70 °C
Ambient
humidity
Operating 35% to 85% (non-condensing)
Storage 35% to 95%
Ambient illuminance Incandescent lamp: 3,000 Ix max. on receiver surface
Sunlight: 10,000 Ix max. on receiver surface
Degree of protection
(IEC 60529)
IEC 60529: IP65 and IP67, JIS C 0920 Annex 1: IP67G
Vibration resistance
(IEC 61496-1)
10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps for all 3 axes
Shock resistance
(IEC 61496-1)
100 m/s
2
, 1000 shocks for all 3 axes
Pollution degree
(IEC 60664-1)
3
Connections Root cable Type of
connection
To sensors: dedicated connector, To external: M12 connector type (5-pin emitter and 8-
pin receiver) or open-ended type
IP67 and IP67G (JIS C 0920 Annex 1) * rated when mated.
* The F3SG-SR meets the degree of protection when the root cable is correctly
connected with the F3SG-SR. The degree of protection is not satisfied with the part
where cable wires are uncovered.
Number of
wires
Emitter: 5, Receiver: 8
Cable length See 5-4-3-1. Root-Straight Cable and 5-4-3-2. Root-Plug Cable for Extended
for more information.
Cable
diameter
6 mm
Minimum
bending radius
R5 mm
Cascading
cable
Type of
connection
To sensors: dedicated connector, To cascading sensors: M12 connector type (5-pin
emitter and 8-pin receiver) or dedicated connector
IP67 and IP67G (JIS C 0920 Annex 1) * rated when mated.
* The F3SG-SR meets the degree of protection when the cascading cable is correctly
connected with the F3SG-SR and the root cable.
Number of
wires
Emitter: 5, Receiver: 8
Cable length
See 5-4-3-5. Cascading Cable for Extended for more information.
Cable
diameter
6 mm
Minimum
bending radius
R5 mm
Extension
cable
- Extended
Socket-
Straight
Cable
- Extended
Plug-Socket
Cable
Type of
connection
M12 connector type (5-pin emitter and 8-pin receiver), IP67* rated when mated
The extension cable meets the degree of protection when the root cable is correctly
connected with the extension cable.The degree of protection is not satisfied with the
part where cable wires are uncovered.
Number of
wires
Emitter: 5, Receiver: 8
Cable length
See 5-4-3-3. Extended Socket-Straight Cable and 5-4-3-4. Extended Plug-
Socket Cable for more information.
Cable
diameter
6.6 mm
Minimum
bending radius
R36 mm
Model
F3SG-SRA-14
F3SG-SRB-14
F3SG-SRA-25
F3SG-SRB-25
F3SG-SRA-45
F3SG-SRB-45
F3SG-SRA-85
F3SG-SRB-85
