16
Chapter1 Ratings and Specifications
F3SG-SR
User’s Manual
Overview and Specifications
Connections Cable
extension
See the section following this table for the restrictions on cable extension.
Root cable In optical synchronization: 100 m max* between power supply and emitter and
between power supply and receiver
In wired synchronization: 100 m max* between power supply and emitter, between
power supply and receiver, and between emitter and receiver
* When the Intelligent Tap (F39-SGIT-IL3) is connected to the sensor, this applies in the
case of the rated power supply of 24 VDC to 24 VDC +20%.
Cascade
connection
Extension cable between sensors: 10 m max. (not including Cascading Cable for
Extended*1 and Root Cable*2.)
*1. F39-JGR3W
*2. F39-JGR3K
Material Housing: Aluminum alloy
Cap: PBT resin
Front window: Acrylic resin
Side-Mount Bracket (Intermediate Bracket)(F39-LSGF): Zinc alloy
FE plate: Stainless steel
Weight
See 1-6-2. List of Models, Current Consumption and Weight for more
information.
Included accessories Instruction Sheet, Quick Installation Manual, Troubleshooting Guide Sticker, Warning
Zone Label, End Cap (for switching Scan Code Selection function), Side-Mount
Bracket (Intermediate Bracket) (F39-LSGF)*
*The quantity varies depending on the protective height.
Protective height of 0160 to 1440: 2 sets (total 4 pcs), 1520 to 2480: 3 sets (total 6
pcs)
Conformity Conforming standards
See Legislation and Standards for more information.
Type of ESPE (IEC 61496-1) F3SG-4SR-: Type 4
Performance Level
(PL)/Safety category
F3SG-4SR-: PL e/Category 4 (EN ISO 13849-1:2015)
PFHD F3SG-SR-: 1.1×10
-8
max. (IEC 61508)
Proof test interval TM Every 20 years (IEC 61508)
SFF 99% (IEC 61508)
HFT 1 (IEC 61508)
Classification Type B (IEC 61508-2)
Model
F3SG-SRA-14
F3SG-SRB-14
F3SG-SRA-25
F3SG-SRB-25
F3SG-SRA-45
F3SG-SRB-45
F3SG-SRA-85
F3SG-SRB-85
To Next Page
