Panasonic FP Series User Manual

Analog unit instructions
1103
Part IV Tool Instructions
Measurement range (switch 1 to 4):
Channel switch Off On Off On Off On Off On
0, 1, 2
1
2
ON
1
2
3
4
5
3, 4, 5
3
4
Measurement Pt100 Pt1000 Ni1000 Resistor
Sampling cycle (switch 5)
switch Off On Off On
1
2
3
4
5
Sampling cycle
0.1 s 1 s
Input wiring
Wiring method
CH0
CH4
CH3
CH2
CH1
CH5
Input line wiring
RTD
RTD = resistance temperature detector
