Panasonic FP Series User Manual

Appendix Programming Information
1276
No. Name Default Values
42 PLC link 0 - Link relays - Send area - Start sending from this word
address
0 0–63
43 PLC link 0 - Link relays - Send area - Number of words to send 0 0–64 words
41 PLC link 0 - Link registers - Send/receive area - Number of words
shared by all linked PLCs
0 0–128 words
44 PLC link 0 - Link registers - Send area - Start sending from this
word address
0 0–127
45 PLC link 0 - Link registers - Send area - Number of words to send 0 0–127 words
57 PLC link 1 - Highest station number in network 16 1–16
50 PLC link 1 - Link relays - Send/receive area - Number of words
shared by all linked PLCs
0 0–64 words
52 PLC link 1 - Link relays - Send area - Start sending from this word
address
64 64–127
53 PLC link 1 - Link relays - Send area - Number of words to send 0 0–64 words
51 PLC link 1 - Link registers - Send/receive area - Number of words
shared by all linked PLCs
0 0–128 words
54 PLC link 1 - Link registers - Send area - Start sending from this
word address
128 128–255
55 PLC link 1 - Link registers - Send area - Number of words to send 0 0–127 words
High-Speed Counter, Pulse-Catch Input, Interrupt Input (Transistor types)
No. Name Default Values
400/
401
High-speed counter:
Channel 0
Unused  Incremental input (X0)
 Incremental input (X0), Reset input (X6)
 Decremental input (X0)
 Decremental input (X0), Reset input (X6)
 Two-phase input (X0, X1)
 Two-phase input (X0, X1), Reset input (X6)
 Incremental input (X0), Decremental input (X1)
 Incremental input (X0), Decremental input (X1), Reset input
(X6)
 Counter input (X0), Incremental/decremental control input (X1)
 Counter input (X0), Incremental/decremental control input
(X1), Reset input (X6)
400 High-speed counter:
Channel 1
Unused  Incremental input (X1)
 Decremental input (X1)
400/
401
High-speed counter:
Channel 2
Unused  Incremental input (X2)
 Incremental input (X2), Reset input (X7)
 Decremental input (X2)
 Decremental input (X2), Reset input (X7)
 Two-phase input (X2, X3)
 Two-phase input (X2, X3), Reset input (X7)
 Incremental input (X2), Decremental input (X3)
 Incremental input (X2), Decremental input (X3), Reset input
(X7)
 Counter input (X2), Incremental/decremental control input (X3)
 Counter input (X2), Incremental/decremental control input
(X3), Reset input (X7)
400 High-speed counter:
Channel 3
Unused  Incremental input (X3)
 Decremental input (X3)

Panasonic FP Series Specifications

General

Mounting	DIN rail
Type	PLC
Communication Interface	RS-232, RS-485, Ethernet (depending on model)
Input Voltage	100-240V AC or 24V DC (depending on model)
Output Type	Relay, Transistor
I/O Points	Varies by model
Operating Temperature	0°C to 55°C
Dimensions	Varies by model
Weight	Varies by model
