Panasonic FP Series User Manual

Appendix Programming Information
1277
No. Name Default Values
401 High-speed counter:
Channel 4
Unused  Incremental input (X4)
 Decremental input (X4)
 Two-phase input (X4, X5)
 Incremental input (X4), Decremental input (X5)
 Counter input (X4), Incremental/decremental control input (X5)
401 High-speed counter:
Channel 5
Unused  Incremental input (X5)
 Decremental input (X5)
401 High-speed counter:
Channel 6
Unused  Incremental input (X6)
 Decremental input (X6)
 Two-phase input (X6, X7)
 Incremental input (X6), Decremental input (X7)
 Counter input (X6), Incremental/decremental control input (X7)
401 High-speed counter:
Channel 7
Unused  Incremental input (X7)
 Decremental input (X7)
402/
401
Pulse output: Channel 0 Unused  Pulse output (Y0, Y1)
 Pulse output (Y0, Y1), Home input (X4)
 PWM output (Y0)
402/
401
Pulse output: Channel 1 Unused  Pulse output (Y2, Y3)
 Pulse output (Y2, Y3), Home input (X5)
 PWM output (Y2)
402/
401
Pulse output: Channel 2 Unused  Pulse output (Y4, Y5)
 Pulse output (Y4, Y5), Home input (X6)
 PWM output (Y4)
402/
401
Pulse output: Channel 3
(32k type only)
Unused  Pulse output (Y6, Y7)
 Pulse output, (Y6, Y7) Home input (X7)
 PWM output (Y6)
403 Pulse catch input: X0 Disable Disable/Enable
403 Pulse catch input: X1 Disable Disable/Enable
403 Pulse catch input: X2 Disable Disable/Enable
403 Pulse catch input: X3 Disable Disable/Enable
403 Pulse catch input: X4 Disable Disable/Enable
403 Pulse catch input: X5 Disable Disable/Enable
403 Pulse catch input: X6 Disable Disable/Enable
403 Pulse catch input: X7 Disable Disable/Enable
404/
405
Interrupt input:
X0
Interrupt 0
Unused Rising edge/Falling edge
404/
405
Interrupt input:
X1
Interrupt 1
Unused Rising edge/Falling edge
404/
405
Interrupt input:
X2
Interrupt 2
Unused Rising edge/Falling edge
404/
405
Interrupt input:
X3
Interrupt 3
Unused Rising edge/Falling edge
404/
405
Interrupt input:
X4
Interrupt 4
Unused Rising edge/Falling edge
404/
405
Interrupt input:
X5
Interrupt 5
Unused Rising edge/Falling edge

Panasonic FP Series Specifications

General

Mounting	DIN rail
Type	PLC
Communication Interface	RS-232, RS-485, Ethernet (depending on model)
Input Voltage	100-240V AC or 24V DC (depending on model)
Output Type	Relay, Transistor
I/O Points	Varies by model
Operating Temperature	0°C to 55°C
Dimensions	Varies by model
Weight	Varies by model
