Appendix Programming Information
1279
No. Name Default Values
400 High-speed counter:
Channel 8 (with pulse
I/O cassette)
Unused  Two-phase input (X100, X101)
 Two-phase input (X100, X101), Reset input (X102)
 Incremental input (X100)
 Incremental input (X100), Reset input (X102)
 Decremental input (X100)
 Decremental input (X100), Reset input (X102)
 Incremental input (X100), Decremental input (X101)
 Incremental input (X100), Decremental input (X101), Reset input
(X102)
 Counter input (X100), Incremental/decremental control input
(X101)
 Counter input (X100), Incremental/decremental control input
(X101), Reset input (X102)
400 High-speed counter:
Channel 9 (with pulse
I/O cassette)
Unused  Incremental input (X101)
 Incremental input (X101), Reset input (X102)
 Decremental input (X101)
 Decremental input (X101), Reset input (X102)
401 High-speed counter:
Channel A (with pulse
I/O cassette)
Unused  Two-phase input (X200, X201)
 Two-phase input (X200, X201), Reset input (X202)
 Incremental input (X200)
 Incremental input (X200), Reset input (X202)
 Decremental input (X200)
 Decremental input (X200), Reset input (X202)
 Incremental input (X200), Decremental input (X201)
 Incremental input (X200), Decremental input (X201), Reset input
(X202)
 Counter input (X200), Incremental/decremental control input
(X201)
 Counter input (X200), Incremental/decremental control input
(X201), Reset input (X202)
401 High-speed counter:
Channel B (with pulse
I/O cassette)
Unused  Incremental input (X201)
 Incremental input (X201), Reset input (X202)
 Decremental input (X201)
 Decremental input (X201), Reset input (X202)
400 Pulse output: Channel
0 (with pulse I/O
cassette)
Unused  Pulse output (Y100, Y101), Home input (X102)
 PWM output (Y100)
401 Pulse output: Channel
1 (with pulse I/O
cassette)
Unused  Pulse output (Y200, Y201), Home input (X202)
 PWM output (Y200)
403 Pulse catch input: X0 Disable Disable/Enable
403 Pulse catch input: X1 Disable Disable/Enable
403 Pulse catch input: X2 Disable Disable/Enable
403 Pulse catch input: X3 Disable Disable/Enable
403 Pulse catch input: X4 Disable Disable/Enable
403 Pulse catch input: X5 Disable Disable/Enable
403 Pulse catch input: X6 Disable Disable/Enable
403 Pulse catch input: X7 Disable Disable/Enable
403 Pulse catch input:
X100
Disable Disable/Enable
