Panasonic FP Series User Manual

Appendix Programming Information
1293
No. Name Default Values
413 TOOL port -sending parity check With-Odd None/With-Odd/With-
Even
413 TOOL port - sending stop bit 1 bit 1 bit/2 bits
413 TOOL port - sending start code No-STX No-STX/STX
413 TOOL port - sending end code/reception done condition CR CR/CR+LF/ETX/Non
e
420 TOOL port- -receive buffer starting address 0 0–12312 (16k type)
0–32762 (32k type)
421 TOOL port - receive buffer capacity 0 0-2048
412 TOOL port - modem connection Disable Disable/Enable
COM Port
No. Name Default Values
412 COM port 1 - communication mode MEWTOCOL-COM
Master/Slave
MEWTOCOL-COM
Master/Slave/Progra
m controlled/PLC
Link/Modbus RTU
Master/Slave
410 COM port 1 -station number 1 1–99
415
COM port 1 - baud rate
1)
9600 baud 115200/57600/38400/
19200/9600/4800/240
0 baud
413 COM port 1 - sending data length 8 bits 7 bits/8 bits
413
COM port 1 -sending parity check
1)
With-Odd None/With-Odd/With-
Even
413 COM port 1 - sending stop bit 1 bit 1 bit/2 bits
413
COM port 1 - sending start code
1)
No-STX No-STX/STX
413 COM port 1 - sending end code/reception done
condition
1)
CR CR/CR+LF/ETX/Non
e
416 COM port 1- -receive buffer starting address 0 0–12312 (16k type)
0–32762 (32k type)
417 COM port 1 - receive buffer capacity 0 0-2048
412 COM port 1 - modem connection Disable Disable/Enable
1)
For PLC Link, the communication format and baud rate settings are fixed:
Data length: 8 bits
Parity: Odd
Stop bit: 1 bit
End code: CR
Start code: No STX
Other system register settings will be ignored.
