Panasonic FP Series User Manual

Appendix Programming Information
1292
Transistor types (C16 and higher)
CPU outputs which have been specified as pulse output or PWM output
cannot be used as normal outputs.
Input numbers X4 to X7 can be used as home input of pulse output
channels 0 to 3. When using the home return function, always set the home
input. In this case, X4 to X7 cannot be used as high-speed counter inputs.
The output numbers for the deviation counter clear signal, which can be
used with the home return function, are fixed for each channel.
For C16: Channel 0 = Y6, channel 1 = Y7
For C32/T32/F32: Channel 0 = Y8, channel 1 = Y9, channel 2 = YA, channel 3
= YB
If used for the deviation counter clear signal, these outputs are not available
as pulse outputs.
Time Constants
No. Name Default Values
430 Time constant of input X0
430 Time constant of input X1
430 Time constant of input X2
430 Time constant of input X3
431 Time constant of input X4
431 Time constant of input X5
431 Time constant of input X6
431 Time constant of input X7
432
1)
Time constant of input X8
432
1)
Time constant of input X9
432
1)
Time constant of input XA
432
1)
Time constant of input XB
433
1)
Time constant of input XC
433
1)
Time constant of input XD
433
1)
Time constant of input XE
433
1)
Time constant of input XF
1.0ms 0.1ms
0.5ms
1.0ms
2.0ms
4.0ms
8.0ms
16.0ms
32.0ms
64.0ms
1)
32k types only
TOOL Port
No. Name Default Values
412 TOOL port - communication mode MEWTOCOL-COM
Slave
MEWTOCOL-COM
Slave/Program
controlled
410 TOOL port -station number 1 1–99
415 TOOL port - baud rate 115200 baud 115200/57600/38400/
19200/9600/4800/240
0 baud
413 TOOL port - sending data length 8 bits 7 bits/8 bits

Panasonic FP Series Specifications

General

Mounting	DIN rail
Type	PLC
Communication Interface	RS-232, RS-485, Ethernet (depending on model)
Input Voltage	100-240V AC or 24V DC (depending on model)
Output Type	Relay, Transistor
I/O Points	Varies by model
Operating Temperature	0°C to 55°C
Dimensions	Varies by model
Weight	Varies by model
