High-Speed Counter, Pulse-Catch Input, Interrupt Input
No.
Name Default Values
400 High-speed counter:
Channel 0
Unused  Two-phase input (X0, X1)
 Two-phase input (X0, X1), Reset input (X2)
 Incremental input (X0)
 Incremental input (X0), Reset input (X2)
 Decremental input (X0)
 Decremental input (X0), Reset input (X2)
 Incremental input (X0), Decremental input (X1)
 Incremental input (X0), Decremental input (X1), Reset input (X2)
 Counter input (X0), Incremental/decremental control input (X1)
 Counter input (X0), Incremental/decremental control input (X1),
Reset input (X2)
400 High-speed counter:
Channel 1
Unused  Incremental input (X1)
 Incremental input (X1), Reset input (X2)
 Decremental input (X1)
 Decremental input (X1), Reset input (X2)
401 High-speed counter:
Channel 2
Unused  Two-phase input (X3, X4)
 Two-phase input (X3, X4), Reset input (X5)
 Incremental input (X3)
 Incremental input (X3), Reset input (X5)
 Decremental input (X3)
 Decremental input (X3), Reset input (X5)
 Incremental input (X3), Decremental input (X4)
 Incremental input (X3), Decremental input (X4), Reset input (X5)
 Counter input (X3), Incremental/decremental control input (X4)
 Counter input (X3), Incremental/decremental control input (X4),
Reset input X5)
401 High-speed counter:
Channel 3
Unused  Incremental input (X4)
 Incremental input (X4), Reset input (X5)
 Decremental input (X4)
 Decremental input (X4), Reset input (X5)
402 Pulse catch input: X0 Disable Disable/Enable
402 Pulse catch input: X1 Disable Disable/Enable
402 Pulse catch input: X2 Disable Disable/Enable
402 Pulse catch input: X3 Disable Disable/Enable
402 Pulse catch input: X4 Disable Disable/Enable
402 Pulse catch input: X5 Disable Disable/Enable
403 Interrupt input:
X0
Interrupt 0
Unused Rising edge/Falling edge
403 Interrupt input:
X1
Interrupt 1
Unused Rising edge/Falling edge
403 Interrupt input:
X2
Interrupt 2
Unused Rising edge/Falling edge
403 Interrupt input:
X3
Interrupt 3
Unused Rising edge/Falling edge
403 Interrupt input:
X4
Interrupt 4
Unused Rising edge/Falling edge
403 Interrupt input:
X5
Interrupt 5
Unused Rising edge/Falling edge
