Chapter 3: FRU Removal and Replacement Procedures
Replacing Node Cooling Fans
100 Quantum DXi6900 G1 User’s Guide
Caution: Use appropriate ESD precautions, including the use of a
grounding strap, when performing this procedure.
Removing and replacing a cooling fan in the Node includes the
following steps:
• Identifying a Failed Cooling Fan in the Node
• Removing a Failed Cooling Fan from the Node
• Installing a Replacement Cooling Fan in the Node
Identifying a Failed Cooling Fan in the Node
The DXi6900 G1 Node contains six cooling fans that provide cooling for
the processors, expansion cards, and memory modules.
To identify the failed cooling fan:
1 Access the remote management console (see Accessing Remote
Management on page 25).
2 Navigate to the Status > Hardware > Details > System Board
page.
3 Note the number (1–6) of the cooling fan that has a Failed status
(see
Figure 54).
