Quantum DXi6900

Chapter 3: FRU Removal and Replacement Procedures
Replacing Array or Expansion Module Hard Drives
Quantum DXi6900 G1 User’s Guide 187
The Qarray drives and status displays. Tray 99 indicates an Array module
(RBOD) and Tray 0 indicates and Expansion module (EBOD) (
Tabl e 15).
Table 15 DXi 6900 G1 Array
and Expansion Location and
Designations
The DXi6900 G1 Array modules (RBODs) and Expansion modules
(EBODs) each support twelve high capacity (4 TB) hard disk drives
(
Figure 112). The Array and Expansion module hard drives are used for
data storage.
Rack
Expansion Module 2-6 (Qarray 2, Tray 6)
Expansion Module 2-5 (Qarray 2, Tray 5)
Expansion Module 2-4 (Qarray 2, Tray 4)
Expansion Module 2-3 (Qarray 2, Tray 3)
Expansion Module 2-2 (Qarray 2, Tray 2)
Expansion Module 2-1 (Qarray 2, Tray 1)
Array Module 2 (Qarray 2, Tray 99)
Node, Redundant Power Supply, and blankoff plates.
Expansion Module 1-7 (Qarray 1, Tray 7)
Expansion Module 1-6 (Qarray 1, Tray 6)
Expansion Module 1-5 (Qarray 1, Tray 5)
Expansion Module 1-4 (Qarray 1, Tray 4)
Expansion Module 1-3 (Qarray 1, Tray 3)
Expansion Module 1-2 (Qarray 1, Tray 2)
Expansion Module 1-1 (Qarray 1, Tray 1)
Array Module 1 (Qarray 1, Tray 99)
