RADWIN2000UserManual Release2.8.30 4‐28
MountingtheLightningProtectionDevices

Figure4‐44:Poleclampsforexternalantennas
GroundinganExternalAntenna
ExternalantennasshouldbeindividuallygroundedusingasuitableGroundingKitsuchasan
AndrewType223158‐2(http://www.commscope.com).
MountingtheLightningProtectionDevices
Theuseoflightningprotectionisdependentonregulatoryandenduserrequirements.The
RADWIN2000ODUisdesignedwithsurgelimitingcircuitstominimizetheriskofdamagedue
tolightningstrikes.RADWINrecommendstheuseofadditionallightningprotectordevicesto
protecttheequipmentfromnearbylightningstrik es.
Inwhatfollows,ODUmaybeanytypeofRADWINoutdoorradiounitandIDUmaybeany
typeofRADWINIDUusedwithsuchproducts(PoEs,IDU‐H,IDU‐Cetc.)
Warning
Donotstandinfrontofaliveantenna.
