RADWIN2000UserManual Release2.8.30 4‐29

MountingtheLightningProtectionDevices

Figure4‐45:RADWINLightningProtectionKit

Table4‐7:LPUKitcontents

Item Quantity View/Remarks

LPU(shown

wrapped)

Uwallclamp 1

RJ‐45

connectors

(shown

wrapped)
